Pool Tile Colors
Blues, turquoises, greens, light neutrals and dark exotic tones, each with matching trims and step pieces.
SeraPool Natural Outdoor & Pool Collection
MATERIAL · DESIGN · APPLICATION
ABOUT THE COLLECTION
Made-to-Order Porcelain Pool & Deck System
Natural-Stone Character with the Performance of Porcelain
SeraPool Natural™ is a porcelain pool tile collection inspired by natural stone, with matching step treads, infinity-edge tile, trim pieces, pool coping, gutter grates, deck drains and slip-resistant deck tile. Pool interior, waterline, steps, edge and deck can all be specified from one coordinated system.
Every Natural product is made to order for your project and shipped direct from the factory to the job site. Send us your drawings or pool dimensions for a complete project quote, and request samples to see true color and face variation.
Faces per Color
Multiple tile faces per color, laid randomly, create the movement of natural stone without a visible repeat.
Deck & Edge Colors
Coping, gutter grates, deck drains and slip-resistant deck tile in eight coordinated stone and concrete looks.
Water Absorption
Porcelain body (EN ISO 10545-3), with a wet pendulum value of PTV ≥ 45 on pool tile, deck tile, coping and grates.
The Natural Design Story
The Tile Decides the Color of the Water
Pool water has no color of its own. What the eye sees comes from the tile below it, the depth of the pool, the angle of the sun, the surrounding landscape and the water chemistry. The same tile can read differently from one project to the next and from morning to evening.
Natural Series colors are grouped by the water effect they create, from clear blue and tropical turquoise to deep lagoon green and soft Mediterranean neutrals. Each color is produced in several faces that are blended randomly on site, so the pool floor and walls show the gentle variation of natural stone.
Unlike natural stone, the porcelain body does not absorb pool water, resists pool chemicals and keeps its color under UV exposure.
Natural Pool Tile Colors
Twenty Colors, Grouped by Water Effect
Pool tile is rectified and 5/16 in. (7.6 mm) thick. Standard formats for most colors are 13×26, 13×13, 6×26 and 6×6 field tile plus 4×13, 4×4 and 2×2 mesh-mounted mosaics. Sizes are nominal; metric sizes are listed in the catalogue.
| Water effect | Color | Code | Faces | Formats |
|---|---|---|---|---|
| Blue | Marin | MA |
9 | All formats |
| Blue Bead | BB |
9 | All formats | |
| Oceano | OC |
9 | All formats | |
| Patchwork Marin | PWM |
9 | 13×26, 13×13 | |
| Piazza Cobalt (deeper blue) | PC |
2 | 13×26, 13×13 | |
| Turquoise | Firuze Mix | FZ |
9 | All formats |
| Piazza Cyan | PCY |
2 | 13×26, 13×13 | |
| Piazza Turquoise | PT |
2 | 13×26, 13×13 | |
| Green | Verde Guatemala (deep green) | VG |
9 | All formats |
| Kaan Mix (light green) | KM |
9 | All formats | |
| Soft / light | Snow White | SW |
9 | All formats |
| Antique Grey | AG |
9 | All formats | |
| Antique Beige | AB |
9 | All formats | |
| Stone mix | Serastone | SS |
9 | All formats |
| Fossil Mix | FM |
18 | All formats | |
| Pool Mix | PM |
18 | All formats | |
| Exotic / dark | Olcay Mix | OM |
9 | All formats |
| Sukabumi | SU |
2 | 13×26, 13×13 | |
| Piazza Green | PG |
2 | 13×26, 13×13 | |
| Tropic | TR |
20 | 13×13 |
“All formats” = 13×26 (33×66 cm), 13×13 (33×33 cm), 6×26 (16.5×66 cm), 6×6 (16.5×16.5 cm), 4×13 mesh (11×33 cm), 4×4 mesh (10×10 cm) and 2×2 mesh (5×5 cm). All faces of a color ship mixed and are meant to be installed randomly. Order samples to judge true color.
The Complete Product System
Every Component from Pool Floor to Deck Edge
Step, edge and trim pieces are made in every pool tile color. Coping, gutter grates, deck drains and deck tile are made in the eight deck colors listed below. Sizes are nominal (inches), with metric in parentheses.
| Component | Sizes & thickness | Code | Notes |
|---|---|---|---|
| In every pool tile color | |||
| Step tread, slip-resistant | 13×26 at 5/16 in. (0.76 cm) or 3/4 in. (1.8 cm) |
ST / OST
|
Also with a right or left return end (SCR, SCL; 3/4 in.: OSCR, OSCL) |
| Infinity-edge tile | 13×26 at 5/16 in. or 3/4 in. |
3366IT / 3366OIT
|
Single or double finished edge |
| Convex (outside) pieces | 2×13 (4×33 cm) and 2×2 corners |
33DB, 33DBA, 33DBK
|
Rounds off outside edges and corners |
| Concave (inside / cove) pieces | 2×13 (4×33 cm) and 2×2 corners |
33IB, 33IBA, 33IBK
|
Coved floor-to-wall transitions; easier cleaning for robotic cleaners |
| Angle trim (L-trim) | 2×2×13 (4×4×33 cm) | 33DK |
Finishes exposed edges |
| In the 8 deck colors | |||
| Slip-resistant pool deck tile | 13×26 at 5/16 in. (0.76 cm) | 3366 |
Matching step treads, infinity-edge tile and trims also available |
| Slot-overflow coping & edge tile | 13×26 at about 3/4 in. (32.7×65.7×1.7 cm actual) |
3366HSH / 3366HST
|
For slot-overflow pools; no gutter grate; 5% slope; epoxy-mesh backed |
| One-piece coping | 10×26 and 13×26 at about 3/4 in. |
2566MH / 3366MH
|
Overflow pools; 90° inside and outside corners; beveled front edge |
| Pool coping | 10×20 and 12×20 |
2550H / 3050H
|
Overflow pools; 90° corners plus convex and concave radius corners |
| Flat coping | 10×20 | 2550FH |
Skimmer pools; flush with the deck; 90° inside and outside corners |
| Flexible gutter grates | 6×20, 8×20, 10×20, 12×20 | GF |
Stainless-steel-wire linked for round and freeform pools; corners and number pieces |
| One-piece gutter grates | 10×26 and 12×26 | GM |
ABS-reinforced underside for straight runs; 90° and 45° corners |
| Concealed gutter grates | 10×26 and 12×26 | GHM |
Grate is hidden from view; removable for cleaning; 90° and 45° corners |
| Deck drain channel | 5×10 (12.5×25 cm); 5×5 corner |
RC, RCP, RCE, RCC
|
Solid, perforated, end and corner pieces; keeps deck runoff out of the pool |
Deck colors: Silver Travertine (ST), Pool Garden Grey (PGG), Pool Garden Anthracite (PGA), Pool Garden Beige (PGB), Cement Grey (CE), Natural Mocha (NM), Cotto (CT) and Beige Stone (BS). These are porcelain products with stone and concrete looks. Slight tonal differences may occur between coping, grates and deck tile.
Edge Detail by Pool Type
Match the Edge System to the Circulation Design
Skimmer Pools
Water is drawn off through skimmers about 6–8 in. below the deck. Specify flat coping, or pool coping where a raised edge is wanted.
Perimeter-Overflow Pools
Water spills into a perimeter gutter. Specify pool coping or one-piece coping with flexible, one-piece or concealed gutter grates.
Slot-Overflow Pools
Water drains through a narrow slot, with no visible grate. Specify slot-overflow coping and edge tile matched to the deck tile.
Infinity-Edge Pools
Water spills over a lowered edge into a catch basin. Specify infinity-edge tile in the pool tile color or the deck color.
Technical Specifications
Tested Performance Data
Values are taken from the manufacturer’s published technical data. Test reports and certificates are available on request for submittals.
| Property | Test method | Value |
|---|---|---|
| Water absorption | EN ISO 10545-3 | Eb ≤ 0.5% (max. 0.6% individual) |
| Breaking strength | EN ISO 10545-4 | ≥ 1,300 N for thickness ≥ 7.5 mm |
| Slip resistance, wet pendulum | EN 16165 Annex C | PTV ≥ 45 for pool tile, deck tile, coping, gutter grates and deck drains (36 and above = low slip potential) |
| Frost resistance | EN ISO 10545-12 | Resistant |
| Thermal shock resistance | EN ISO 10545-9 | Resistant |
| Crazing resistance | EN ISO 10545-11 | Resistant |
| Linear thermal expansion | EN ISO 10545-8 | ≤ 9 × 10-6 K-1 |
| Moisture expansion | EN ISO 10545-10 | ≤ 0.05% |
| Chemical resistance | EN ISO 10545-13 | Class A for household cleaning products and swimming pool salts, and for low-concentration acids and bases |
| Impact resistance | EN ISO 10545-5 | Coefficient of restitution ≥ 0.55 |
| Lead release | EN ISO 10545-15 | < 0.1 mg/dm² |
| Reaction to fire | — | A1 / A1fl |
| Tensile adhesion with C2 cementitious adhesive | EN 12004-2 | ≥ 1 N/mm² |
| Edges / size tolerance | EN ISO 10545-2 | Rectified; size deviation up to 0.4 mm (1/64 in.) |
| Product standard & quality | EN 14411 | CE marked; manufactured under an ISO 9001:2015 quality system |
The manufacturer reports slip resistance as Pendulum Test Value (PTV) under EN 16165. It does not publish DCOF values (ANSI A326.3). If your project or local code requires DCOF, contact us before specifying.
Installation Guidance
Manufacturer Recommendations for Submerged Installation
Substrate & Setting
- Waterproof the shell, then wait at least 5 days after waterproofing before tiling. Leak-test the pool shell before tile installation.
- The manufacturer specifies a C2TE S1 deformable cementitious adhesive (EN 12004). In US practice, use an improved modified mortar (ANSI A118.15) rated for submerged use by its manufacturer.
- Comb the adhesive in straight lines with a notched trowel for full coverage with no voids. Seat each tile with a rubber mallet.
- Leave at least 3/8 in. (1 cm) at walls and plan movement joints. In the US, follow TCNA EJ171.
Joints, Grout & Layout
- SeraPool Natural tile is rectified: set with a 1/8 in. (3 mm) joint, as the manufacturer specifies. Protect tile edges from impact during installation.
- Grout no sooner than 24 hours after setting. Use a flexible, pool-rated grout approved by the setting-material manufacturer.
- Blend tile from several boxes and lay all faces randomly. Do not break the face set into separate areas.
- Coping is designed for a 5% slope toward the overflow gutter. Cut porcelain with diamond tools, and cut complex shapes by waterjet.
Product suitability, slip resistance, waterproofing, substrate preparation, drainage, pool chemistry, climate exposure, installation method and local code requirements must be confirmed for each project. Consult qualified design, engineering, waterproofing and installation professionals before final specification.
Collection Resource
Download the SeraPool Natural Catalogue
All 20 pool tile colors with every face, all formats and trim pieces, coping, gutter-grate and deck-drain sections, technical data and installation guide (PDF, 136 pages).
Talk to a Real Person About Your Pool Project
Send us drawings, pool dimensions or a specification for a complete quote covering pool tile, trims, step treads, coping, gutter grates, deck drains and deck tile, plus samples, freight and lead time.
